Description
Big Pump Features.
Axis pumps offer full control, wireless smart device programming, DC motor quiet operation, and output calibration. Features that have traditionally been reserved for considerably larger and more expensive pumps.
Axis 20
Max Head: ≈5ft (≈1.5m)
Flow Rate: ≈185gph (≈700lph)
Power Consumption: Variable, 12W max
Recommended Tank Size: Up to ≈15 gallons
Axis 40
Max Head: ≈9ft (≈2.8m)
Flow Rate: ≈400gph (≈1500lph)
Power Consumption: Variable, 20W max
Recommended Tank Size: Up to ≈40 gallons
Axis 90
Max Head: ≈10ft (≈3m)
Flow Rate: ≈925gph (≈3500lph)
Power Consumption: Variable, 40W max
Recommended Tank Size: Up to ≈90 gallons
Included Pump modes
Schedule
Create a custom program with changing flow over time.
Feed
Temporarily reduces flow to prevent food from being cycled into the overflow.
Calibrate
Calibrate your pump to your aquarium. Set min and max flow levels.
Coordinate Feed/Maintenance Modes- Turn all of your AI pumps on or off with a control button on a single pump.
Prevent back-siphon- With calibration set, instead of powering off, a pump will continue to run without producing flow, preventing siphoning, which could result in air bubbles when the pump resumes its scheduled operation!
With Axis you get exactly what you need, starting with Axis 20 which is perfect for tanks 15 gallons or less.
Wide Range Compatibility
Small package. Large application.
Nozzle Sizes (Barbed)
Axis 20 Small: 0.5in. 12mm Large: 0.625in. 16mm
Axis 40 Small: 0.625in. 16mm Large: 0.75in. 20mm
Axis 90 Small: 0.75in. 20mm Large: 1in. 25mm
Simple Built-in Control
All AI devices include smart control standard. Choose from the myAI® or Mobius app on any iOS or Android device to easily set up or program your AI equipment. Add Neptune Fusion control via Apex with Apex and MXM module.
Technical Specifications
Axis 20
Dimensions
Width 2.125 in. (54 mm)
Height 5.5 in. (139.7 mm)
Specifications
Max Head ≈5 ft. (≈1.5 m)
Flow Rate ≈185 gph (≈700 lph)
Recommended Tank Size Up to ≈15 gallons
Power Consumption Variable, 12W max
Input 100–240VAC, 50-60Hz, 1A
What’s in the Box
AI Axis™ 20 Pump with Integrated Driver
Power Adapter with Universal Plug
Adapter Set
Quick Start Guide
Axis 40
Dimensions
Width 2.44 in. (62 mm)
Height 6.625 in. (168.2 mm)
Specifications
Max Head ≈9 ft. (≈2.8 m)
Flow Rate ≈400 gph (≈1500 lph)
Recommended Tank Size Up to ≈40 gallons
Power Consumption Variable, 20W max
Input 100–240VAC, 50-60Hz, 1A
What’s in the Box
AI Axis™ 40 Pump with Integrated Driver
Power Adapter with Universal Plug
Adapter Set
Quick Start Guide
Axis 90
Dimensions
Width 2.91 in. (74 mm)
Height 7.75 in. (196.85 mm)
Specifications
Max Head ≈10 ft. (≈3 m)
Flow Rate ≈925 gph (≈3500 lph)
Recommended Tank Size Up to ≈90 gallons
Power Consumption Variable, 40W max
Input 100–240VAC, 50-60Hz, 1A
What’s in the Box
AI Axis™ 90 Pump with Integrated Driver
Power Adapter with Universal Plug
Adapter Set
Quick Start Guide
