REEFER MAX Concept

Fully equipped smart systems that provide you with everything you need for a thriving reef.

The premium REEFER MAX series features the entire REEFER G3+ range in a Plug & Play configuration that includes all our smart lighting, filtration, and circulation devices, so you can enjoy the full Red Sea ecosystem experience, operate every aspect via your ReefBeat App, and be at ease knowing that all the essential equipment is compatible and at the best possible price!



Eurobraced ultra-clear glass

REEFER MAX G3+ aquariums are constructed from ultra-clear glass with increased thickness of up to 19 mm/0.75”. All REEFER models are eurobraced for extra strength, and bonded with high quality euro-silicone for long-lasting, structural integrity.



10-19mm Ultra clear glass

(Thickness per model)



Euro-brace aquariums



Extra Fortified marine-spec cabinet

REEFER aquariums are mounted on marine-spec plywood cabinets with leveling feet, with REEFER 625 models and above further reinforced with front aluminum supports.

Laminated plywood panels

Epoxy painted doors

Adjustable feet

Stainless steel hinges



Silent downflow system

The enlarged rectangular inlet to the downflow pipe reduces turbulence, resulting in a quieter operation.



Optimized water circulation

REEFER G3+ models feature a fully redesigned flow system, delivering up to 50% more water circulation. The larger models also have wider return piping and upgraded nozzles to further maximize flow.



High precision gate flow valve

All REEFER MAX G3+ models benefit from the new ReefGate, high-precision bespoke gate valve on the downflow pipe, allowing for easy regulation of the flow and a near silent operation.



Improved return outlets & overflow box

The central overflow box is fitted with a removable surface skimmer for easy maintenance, and the return outlets on all models have hydrodynamically superior pipping for improved water distribution.

Dual return pump outlets

Highly effective surface skimming

Optimal water circulation



Includes: ReefControl Pro + ATO Module

All REEFER MAX G3+ systems come with the ReefControl Pro that includes ReefSense pH/Temp Probe and the ATO Module – an exceptionally reliable automatic top-off system. The ReefControl Pro, allows the addition of the full range of ReefSense probes and sensors, and ReefControl Power delivering a flexible suite of monitoring and control options.



Includes: ReefLED G2 115 or ReefLED G2 170 lighting

Uniquely designed with light intensity and spectrum that are 100% utilized by corals, the ReefBeat App-controlled ReefLED provides optimal growth, vivid colors, and an elegant gentle shimmer throughout the aquarium.



Reef-safe lighting

Optimal coral growth



500 RL115 par

At surface level



500 RL170 par

At surface level



Includes: ReefRun G2 DC Pump

The ReefRun G2 DC Pumps are highly efficient, powerful yet virtually silent pumps, with flow rates ranging from 4000 to 12000 lph (1060-3200 gph). They can be operated locally with their integrated Flow Controllers, or can be linked to ReefBeat App via the ReefRun Dual Controller for advanced features and control.



Includes: ReefMat

A fully automated,ReefBeat App-controlled roller filter that keeps your aquarium water crystal clear, with a unique mat replacement system that allows you to switch rolls with zero hassle.



Easy setup

Easy maintenance

Solid state sensor



Includes: REEFER DC Skimmer

The ReefBeat App-controlled REEFER DC Skimmers include self-leveling technology that prevents over-skimming and prevents full cups from spilling while continuing to aerate the water.



Includes: ReefWave

The ReefBeat App-controlled ReefWave provides an optimal REEF-SPEC water flow for corals in a wide range of reefscapes, combining a smooth running and energy-efficient sine-wave motor drive with superior vibration damping mounts and dual bearings.



Register your brand-new REEFER MAX within 90 days of purchase

And turn your standard 3-year warranty into 5 years, at no extra cost!



Models	Reefer MAX 200 G3+	Reefer MAX 300 G3+	Reefer MAX 425 G3+	Reefer MAX 625 G3+	Reefer MAX 750 G3+
Total system water volume	52.8 gal	79.3 gal	114.4 gal	163.8 gal	198.1 gal
Display tank water vol.	41.7 gal	65 gal	90.6 gal	131.3 gal	158.5 gal
In-Cabinet sump water vol.	11.1 gal	14.3 gal	23.8 gal	32.5 gal	39.6 gal
Display tank Length	23.6 "	35.4 "	47.2 "	59.1 "	70.9 "
Display tank width	22.6 "	22.6 "	23.6 "	25.6 "	25.6 "
Display tank height (excluding light unit)	20.9 "	21.7 "	21.7 "	23.6 "	23.6 "
Total system height (excluding light unit)	55.1 "	55.9 "	55.9 "	58.3 "	58.3 "
Ultra-clear front glass	0.39 "	0.47 "	0.47 "	0.75 "	0.75 "
Ultra-clear side glass	0.47 "	0.47 "	0.59 "	0.75 "	0.75 "
Bottom glass	0.39 "	0.47 "	0.47 "	0.59 "	0.75 "
Back glass thickness	0.31 "	0.39 "	0.47 "	0.75 "	0.75 "
Bracing	Euro brace			Euro brace + bottom brace
Aquarium Support	Floating look with aluminum support
ReefLED advanced light system	1 x ReefLED G2 115 - included	2 x ReefLED G2 115 - included	2 x ReefLED G2 115 - included	2 x ReefLED G2 170 - included	3 x ReefLED G2 170 - included
Water circulation	1 x ReefWave25 (1,980 gph) linear wave pumps - included	2 x ReefWave25 (1,980 gph) linear wave pumps - included	2 x ReefWave45 (3,960 gph) linear wave pumps - included
Main system pump	1x ReefRun G2 4000 (530-1060 gph) - included	1x ReefRun G2 4000 (530-1060 gph) - included	1x ReefRun G2 6000 (950-1700 gph) - included	1x ReefRun G2 8000 (1080-2200 gph) - included	1x ReefRun G2 8000 (1080-2200 gph) - included
Return outlet nozzles	1x 25mm (Single pump)	1x 25mm (Single pump)	2x 25mm (Single or dual pump)	2x 25mm (Single or dual pump)	2x 32mm (Single or dual pump)
Hydrodynamic piping with Gate valve
Protein Skimmer	RSK DC 300 (Water flow 265 gph air flow 130 gph) - included	RSK DC 300 (Water flow 265 gph air flow 130 gph) - included	RSK DC 600 (Water flow 400 gph air flow 195 gph) - included	RSK DC 900 (Water flow 530 gph air flow 235 gph) - included	RSK DC 900 (Water flow 530 gph air flow 235 gph) - included
ReefMat / NanoMat	ReefMat 250 included	ReefMat 500 included	ReefMat 500 included	ReefMat 1200 included	ReefMat 1200 included
Slide out control panel	Slide-out control panel 25 Included	Slide-out control panel 60 Included	Slide-out control panel 60 Included	Slide-out control panel 60 Included	Slide-out control panel 60 Included
ReefControl Controller	Pro Controller	Pro Controller	Pro Controller	Pro Controller	Pro Controller
ATO Module with integrated Temp Sensor	Included
ReefSense pH & Temp Probe
